Specifications
MIG Welding
 Infinite output voltage controls which can be adjusted as you weld.
 Infinite wire speed control.
 Heavy duty, professional quality Trafimet 250 Amp MIG gun with 10’ hose.
 Factory pre-wired and ready for optional spool gun.
 Separate MIG shielding gas connection for Argon/CO2.
 Heavy duty double drive motor easily handles 11 and 33 pound wire spools.
 Comes with two sets of drive wheels to handle .030” (.8 mm), .040” (1.0 mm) and .045” (1.2 mm) MIG
wire.
 Quick feed button allows for faster loading of MIG wire into the gun.
 Comes with three .040” (1.0 mm) contact tips.
TIG Welding
 250 Amp rated TIG Torch with 12’ hose.
 Heavy duty metal foot petal with 15’ control wiring.
 Separate TIG shielding gas connection for Argon.
 Three TIG gas nozzles, one collet body, three collets, one short cap and one long cap.
Arc Welding
 300 Amp electrode holder with 10’ cable assembly.
Common Features
 300 Amp ground clamp with 10’ cable assembly
 Tank tray that holds up to 9.5” diameter tacks weighing less than 330 pounds.
 Heavy duty 10” solid rubber rear wheels and 3” castors in front for mobility.
 Argon/CO2 regulator with 5’ hose included for MIG and TIG applications.
 36V heated regulator output (optional heated regulator available)
 Circuit breaker for overload protection.
 6’ grounded power cord (plug not included).
Table 1
Rated Input 50 Amps @ 220 Volts, 60 Hz, Single Phase
Rated Output - Arc 30- 230 Amps, 21.2 to 29.2 Volts DC
Rated Output - MIG 50 - 250 Amps, 16.5 to 26.5 Volts DC
Rated Output - TIG 20 - 230 Amps, 10.8 to 19.2 Volts DC
Duty Cycle - Arc 60% at 230 Amps, 100% at 178 Amps
Duty Cycle - MIG 60% at 250 Amps, 100% at 194 Amps
Duty Cycle - TIG 60% at 230 Amps, 100% at 178 Amps
Welding Wire Spool Sizes
8" x 2" (200mm x 50mm)
12" x 4" (300mm x 100mm)
Weight 150 Pounds
Features & Benefits
