Dake Model Super Technics 350CE - Manual (Page 13)

13
350 SUPER TECHNICS 350 SUPER TECHNICS 350 SUPER TECHNICS 350 SUPER TECHNICS 350 SUPER TECHNICS
N° RIFERIMENTO DENOMINAZIONE REFERENCE N° DESCRIPTION
N° RIFERIMENTO DENOMINAZIONE REFERENCE N° DESCRIPTION
REFERENCE N° DESCRIPTION
REFERENCE N° DESCRIPTION
77 Ring DPSM 50728
78 Cylindric pin Ø 5x12
79 Disk shaft
80 Disk
81 Disk shaft flange
82 TCCE M12x35 l.h. Screw
83 Fixed blade guard
84 Grain M8
85 Front head cover
86 Cooling distributor
87 Coolant tube
88 Grain M6
89 Mobile blade guard
90 Ring seeger Ø 60E
91 Pin
92
93 Tie rod support
94 Screw M6
95 Screw M6
96 Tie rod
97 Ring seeger Ø 10E
98 Tie rod support pin
99 Ring OR 4205
100 GUK M20x1 ring nut
101 Worm screw
102 Worm screw spacer
103 Ring seeger Ø 62I
104 Bearing 3305
105 Ring SM 32527
106 OR-Rings 4312
107 Front motor flange
108 Motor shaft (rotor)
109 Key 5x6x35
110 Washer
111 Stud bolt
112 Nut
113 Motor housing and stator
114 Switch box
115 Ring OR 3081
116 Motor rear cover
117 Ring seeger Ø 25E
118 Head cover gasket
119 Nilos Ring 4205 AV
120 Bearing 4205
121 Motor fan
122 Fan cover
123 Bearing 609
124 Ring seeger Ø 9E
125 Pump connection box
126 Gasket
127 Screw M4
128 Coolant pump
129 Washer
130 Screw M6
131 Clutch cone
132 Worm wheel
133 Clearance adjustment ring
134 KM8 M40x1,5 ring nut
135 Safety washer MB8
136 Cup springs 50x25 - 4x3
137 Disk shaft flange pin
