SECTION 4 – MAINTENANCE
4-2
SPECIFICATIONS
Working Transport Transport Transport Machine Roller
Width Width Height Length Weight Diameter
30’ 13’4” 9’11” 35’8” 18,600# 42”
Tire Size Rating Recommended Inflation Pressure
12.5Lx15 LRF 90 PSI
Hub Size Rating Recommended Wheel Recommended Axle
Nut Torque Nut Torque
HD812 6100 LB. 170 ft.-lbs. 45 ft.-lbs., loosen until
20 MPH Maximum first slot is aligned with
hole in axle, install cotter
pin, bend to retain.
STORAGE
1. Follow steps outlined in “UNHOOKING LAND ROLLER FROM TRACTOR IN FIELD POSI-
TION”.
2. Clean and remove all excessive dirt and grease from Land Roller.
3. Grease all zerks.
4. To prevent rusting, repaint any areas that have been worn, chipped or scratched.
5. Apply grease* to any exposed part of cylinder shafts.
*NOTE: Before returning Land Roller into service, all grease must be removed from cylinder
shafts to prevent damage to seals.
