Summers 30' Superroller User Manual
Page 23
SECTION 2 - ASSEMBLY
1
1
2
2
A
A
B
B
-110
4/3/2007
9LR3042.iam/
DO NOT ATTACH ROD END OF CYLINDERS
TO HITCH UNTIL CYLINDERS
HAVE BEEN CYCLED 3 TIMES
NOTE: WINGS, DRUMS, WHEELS,
PIVOT ARMS (WHICH WERE
PREVIOUSLY INSTALLED) HAVE BEEN
EXCLUDED FROM THIS DRAWING FOR
EASE OF REPRESENTATION.
2-13
PC3. Location and final tightening of the hardware will be after the hydraulic cylinders have been
cycled.
Figure 10
