Summers 3-Rank Superweeder - Manual (Page 43)

5-3
SECTION 5 – SET-UP INSTRUCTIONS CABLE AUTO-FOLD (16 Ft. Hitches)
Ref. Part No. Description Qty.
1 8D2100 CHAIN, 6 link 1
2 8D3152 U-BOLT, 1/2 x 3-3/8” (16’ New) 2
4 8D4012 CHAIN, 5/16” x 18 links - 16’ hitch 2
8D4020 CABLE, 1/4” x 13’ - 16’ hitch 1
5 8D4024 CABLE CLAMP, 1/4” 2
6 8D4026 CABLE THIMBLE, 1/4” 1
7 8D4030 LINK, cable and chain attach. 4
8 8D4040 DRAWBAR CABLE ANCHOR, U-bolt 1
9 8D4050 SPRING, auto cable fold 2
10 8D4110 MOUNTING PLATE, U-bolt 1
11 8D4120 ANGLE BRACKET, latch spring 1
12 8D4130 MOUNTING PLATE, pivot 2
13 8D4140 MOUNTING BRACKET, pivot, left 1
14 8D4150 MOUNTING BRACKET, pivot, right (Not Shown) 1
15 8D4160 MOUNTING PLATE, spring anchor 2
16 8D4170 MOUNTING BRACKET, spring anchor 2
17 8D4200 LATCH ASSEMBLY, 16’ hitch 1
18 8D4210 CABLE PULL W/TUBE 2
19 8D4220 ARM, long left, 16’ hitch 1
8D4230 ARM, long, right (Not Shown), 16’ hitch 1
20 8F9410 APPLICATOR HOSE, 3/8” (10-1/2’ for 16’ Hitch) Per Ft. X
21 8R4190 SELECTOR SPRING 1
22 8R4335 EYE BOLT, 3/8” NC 1
23 8R6145 EYE BOLT 3/4” 2
24 8X0034 CAPSCREW, 7/16” x 1-3/4” Z (Gr. 5) 3
25 8X0062 CAPSCREW, 1/2” x 2” Z (Gr. 5) 2
26 8X0067 CAPSCREW, 1/2” x 2-1/4” Z (Gr. 5) 2
27 8X0095 CAPSCREW, 5/8” x 5” Z (Gr. 5) 16
28 8X0107 CAPSCREW, 3/4” x 2” Z (Gr. 5) 2
29 8X0113 CAPSCREW, 3/4” x 5” Z (Gr. 5) 2
30 8X0144 CAPSCREW, 1” x 9-1/2” Z (Gr. 5) 2
31 8X0202 NUT, lock 3/8” NC, Z (Nylon) 1
32 8X0234 NUT, lock 7/16” NC, Z (Nylon) 3
33 8X0240 NUT, hex 1/2” NC (Z) 4
34 8X0242 NUT, lock 1/2” NC, Z (Nylon) 4
35 8X0250 NUT, hex 5/8” NC (Z) 18
36 8X0261 NUT, lock 3/4” NC Z (Nylon) 4
37 8X0281 NUT, lock 1” NC Z (Nylon) 2
38 8X0303 LOCKWASHER, 1/2” (Z) 4
39 8X0304 LOCKWASHER, 5/8” (Z) 18
40 8X0330 WASHER, 1-1/4” x 17/32” ID (Z) 8
41 8X0331 WASHER, 1-1/4” x 15/32” ID (Z) 1
42 8Z0232 DECAL, warning - stand clear (2x7” Auto-Fold) 2
