Vi-K2/Vi-K3 Universal
Keyboard
Vi-K2 Universal Keyboard User Manual
19
5 Current Protocol Support
A Vi-K2/Vi-K3 is capable of controlling a mixture of two different types of dome. All domes of one type must
be connected to the “
DOMES-1” output, and all domes of the other type must be connected to the
“
DOMES-2” output. These outputs must each be allocated one of the following protocol numbers (See
sections 2.2.3 and 2.2.4):
Note that some domes support protocols from other manufacturers, or may be controlled via a protocol
converter. It is important to select the correct protocol from the list below, not necessarily the manufacturer
of the dome.
Protocol
Number
Protocol Name Output
Used Baud
Rate Comments
1 Slave RS485 9600 Select this protocol in all slave Vi-K2/Vi-K3’s and if
domes are connected to dome-enabled DVRs.
2 JVC RS485 9600 Direct connection via twisted pair.
3 Molynx RS485 9600 Connect directly to Molynx receivers via twisted pair.
4 Dennard RS485 9600 Direct connection via twisted pair.
5 VCL RS485 9600 Direct connection via twisted pair.
6 Sanyo RS485 9600 Direct connection via twisted pair.
7 BBV RS232 9600 Connect to a BBV transmitter such as the TX1000/8,
which provides control of BBV compatible domes &
receivers via coax.
8 BBV 20mA 1200 Connection to BBV compatible receivers via twisted
pair. The RX100 receivers provide coax or RS485
control of a range of dome domes as supported by
BBV.
9 Forward Vision
(VCL) RS485 9600 Direct connection via twisted pair. Note that the
dome must be purchased with the VCL-based
protocol option.
10 Mercer RS485 9600 Direct connection via twisted pair.
11 Merit Lilin (MLP1) RS485 9600 Direct connection via twisted pair.
12 Borsatec RS485 9600 Direct connection via twisted pair.
13 Samsung RS485 9600 Direct connection via twisted pair.
14 Pelco-D (2400) RS485 2400 Direct connection via twisted pair at standard Pelco
baud rate. Many domes use this protocol.
