8.1 Number of Cameras
Three switch sections are used to specify the number of cameras in the system. If there are less than eight
cameras, connect them to consecutive camera inputs, starting with input 1.
Number of
Cameras
S1-1
S1-2
S1-3
*Programm
able
OFF
OFF
OFF
2
ON
OFF
OFF
3
OFF
ON
OFF
4
ON
ON
OFF
5
OFF
OFF
ON
6
ON
OFF
ON
7
OFF
ON
ON
8
ON
ON
ON
*The Programmable option allows individual selection of which cameras are to be sequenced on the
Monitor A output and which cameras are to be sequenced on the Monitor B output by means of SET
operations (section 6.1 and 6.2).
8.2 Random Sequencing
The transmitters are provided with a random sequence mode which can be used on both Monitor A and
Monitor B. This mode is useful when a monitor is on public display for deterrence purposes. The pseudo
random sequence is designed to ensure that all cameras will be selected with equal frequency but in a
unpredictable order.
Set this switch on if you want cameras sequence randomly, and set it off if you want camera to sequence in
normal order (1,2,3 etc):
S1-5
Sequence Mode
OFF
Normal
ON
Random
8.3 Alarm Modes
Set this switch off if you do not want alarms latched and if you do not require audible indication of the
alarms. Set this switch on if you require alarms to be remembered until manually acknowledged by an
operator, and if you want an audible warning of alarms.
S1-6
Alarm Mode
OFF
Unlatched
ON
Latched
