When you invoke the OSD, a screen similar to the one below appears:
Note: 1. The diagram depicts the Administrator’s Main Screen. The
User Main Screen does not show the F4 and F6 functions,
since these are reserved for the Administrator and can’t be
accessed by ordinary Users.
2. OSD always starts in List view, with the highlight bar at
the same position it was in the last time it was closed.
3. Only the ports that have been set accessible by the
Administrator for the currently logged in User are visible
(see SET ACCESSIBLE PORTS, p. 4-10, for details).
F1:GOTO F3:SET F5:SKP F7:SCAN X
F2:LIST F4:ADM F6:BRC F8:LOUT z z z
ADMINISTRATOR
LIST:ALL
SN PN QV NAME
01 14 ATEN INTL.CO. 1
01 15 ATEN INTL.CO. 2
01 16 ATEN INTL.CO. 3
02 01 FAX SERVER 1
02 02 FAX SERVER 2
02 03 WEB SERVER 1
02 04 WEB SERVER 2
02 05 MAIL SERVER 1
