ATEN ACS-1208A User Manual
Page 19
5. Firmware Upgrade Port
The Firmware Upgrade Cable that transfers the firmware upgrade
data from the administrator’s computer to the ACS-1208A /
ACS-1216A (see p. 5-2), plugs into this RJ-11 socket.
6. Firmware Upgrade Recovery Switch
During normal operation and while performing a fimware
upgrade, this switch should be in the NORMAL position. See p.
5-8 for details about the use of this switch.
7. Console Port Section
If this is a Single Station installation, or if this is the First Station
unit of a daisy chained installation, the keyboard, monitor, and
mouse plug in here.
2003-06-20
Introduction
1-11
