3. Plug the power adapter cable into the Master View’s Power Jack,

then plug the power adapter into an AC power source.

4. Turn on the power to the computers.

Daisy Chaining

To control even more computers, up to 31 additional switches can be
daisy chained down from the first unit. As many as 512 computers can
be controlled from a single console in a complete installation. Tables
showing the relation between the number of computers and the number
of Master View ACS-1208A / ACS-1216A units needed to control them
are provided on p. A-1 in the Appendix.

To set up a daisy chained installation, do the following:

1. Make sure that power to all the devices you will be connecting up

has been turned off.
