Ab c d – AMETEK 1970 Drive Check Control User Manual
Page 4

1970.C1
4/99 • Z26
1M
DRIVE-CHEK DIMENSIONS FOR SERIES 1980
NEMA 1 NEMA 4 and 12
NO. OF
A
B
C
D
CIRCUITS
2-4
7.31
4.42
5.00
9.75
5-6
9.75
6.86
5.00
9.75
7-8
12.19
9.30
5.00
9.75
9-12
17.07
14.18
5.00
9.75
13-16
23.48
20.60
5.50
10.25
17-20
28.36
25.48
5.50
10.25
21-24
33.24
30.36
5.50
10.25
NO. OF
A
B
C
D
CIRCUITS
2-4
7.31
4.42
5.00
11.40
5-6
9.75
6.86
5.00
11.40
7-8
12.19
9.30
5.00
11.40
9-12
17.07
14.18
5.00
11.40
13-16
23.48
21.62
7.00
13.40
17-20
28.36
26.50
7.00
13.40
21-24
33.24
31.38
7.00
13.40
Dimensions shown apply
when platform and base
are parallel.
1080 NORTH CROOKS ROAD • CLAWSON, MI 48017 USA
800-635-0289 • 248-435-0700 • Fax 248-435-8120
www.patriotsensors.com • www.ametek.com
