Specifications

General Specifications

Connector

5-pin 12mm Euro Micro

Displacement

1” to 72” in 1” Increments

Electrical Specifications

Input Voltage

24 VDC ±20%

Current Draw

1.1W (44mA typical)

Dead Band

2.75”

Null Zone

2.75”

Non-linearity

less than ± 0.03% of stroke or ± 0.013”, whichever is greater

Repeatability

0.001%

Hysteresis

less than 0.001”

Operating Temperature:

-40ºC to 85ºC

Analog Output Specifications

Voltage Output Minimum Load Resistance
Output Current

2K Ohms
Guaranteed 5mA minimum for voltage units

Analog Ripple

1 mV maximum

Current Output Maximum Load Resistance 500 Ohms
Update Time

1ms

Resolution

Internal

.00006”

Output

16-bit

Output Type

Voltage Output

0V to 10V, 10V to 0V

Current Output

4mA to 20mA, 20mA to 4mA

Enclosure Rating - IP-67

Approvals - CE (EMC)

Note: Specifications are based on a 48” stroke with floating magnet SD0551500 and 1/8” gap.

AMETEK Automation & Process Technologies has checked the accuracy of this manual at the time it was approved for printing. However, this manual

may not provide all possible ways of installing and maintaining the LDT. Any errors found in this manual or additional possibilities to the installation and

maintenance of he LDT will be added in subsequent editions. Any comments you have for the improvement of this manual are welcomed. AMETEK

reserves the right to revise and redistribute the entire contents or selected pages of this manual. All rights to the contents of this manual are reserved by

AMETEK.

Options

X = No Options

P= Programmable Zero and Span

Output

V0 = 0 to 10

V1 = 10 to 0

C2 = 20 to 4mA

C4 = 4 to 20mA
Stroke Length

Insert stroke length to 1 inch or

25mm. Enter as a four-place number.

Example: 12.0 inch stroke is entered

as 0120 (E) or 100mm is entered as

0100 (M).
Units of Measure

E = English US Inches / M = Metric
Magnet Type

FM = Floating Magnet (Standard)

SM = Slide Magnet Top Swivel

SF = Slide Magnet Front Swivel

X = No Magnet

955 eBrik™

955e

0120

Part Numbering

Accessories

Item

Part Number

Slide Magnet

SD0521800

Large Float Magnet

SD0551500

Mounting Foot

SD0522000

6 Ft, 5 Pin Straight Cable

949019L6

12 Ft, 5 Pin Straight Cable

949019L12

6 Ft, 5 Pin Right Angle Cable

949020L6

12 Ft, 5 Pin Right Angle Cable

949020L12
