950MD
Mill-Duty Housing
4
1080 N. Croo ks R o ad • C laws o n, MI 48017 • 8 00-635-0289 • 248-435-0700 • Fax 24 8- 435-8120 • www.ametekapt.com
Connector
X
Standard 1/2 inch NPT conduit fitting (It is suggested
to order a quick disconnect connector on the LDT)
C
MS Style Connector and Mate on Side of Housing
(for 950 LDT)
C2
Environmental MS connector and mate on side of
housing (specify the Gemco LDT to be used within the
body of the order; if the housing is being used with a
competitive probe, please contact a Customer Service
Representative at 800.635.0289.
C3
5 Pin, 12mm, Euro Connector on Side of Housing (for
952A or 953A w/connector option S only)
C4
6 Pin, 12mm, Euro Connector on Side of Housing
(for 953D and 953SSI w/connector option S only)
C5A 10 Pin STD - to 953A 5 Pin Euro
C5D 10 Pin STD - to 953D 6 Pin Euro
NC No Head Cover on the 950MD Housing
W
Special Head cover for LDT using water cooled jacket.
Allows entry and exit of water lines. NOTE: This option
does not support connector options. This option relies
on the LDT connector option for field wiring.
CGA Cord Grip Stainless Steel for Cable dia. .19" - .25"
CGB Cord Grip Stainless Steel for Cable dia. .25" - .31"
CGC Cord Grip Stainless Steel for Cable dia. .31" - .38"
CGP Cord Grip PVDF for Cable dia. .1" - .3"
Connector
X None
V Vortex air cooler
B1
Protective boot – neoprene coated nylon
(-60°F to +250°F)
B2
Protective boot – silicone
coated fiberglass (-100°F to +550°F)
B3
Protective boot – Teflon coated
fiberglass (-100°F to 500 °F)
R
Rear mount spherical rod end 3/4"
F
Front mount spherical rod end 3/4"
RS
Stainless steel rear mount spherical
rod end 3/4” with 304 stainless steel
mounting bolt
FS
Stainless steel front mount spherical rod
end 3/4” with 304 stainless steel mounting
bolt
L
Delrin liner for extended life cycle
on longer horizontal applications (used
to protect the LDT rod assembly)
SB
304 stainless steel boot
A Barrel Air Purge
NOTE: Consult Factory for Custom Configurations.
Accessories
Item Part Number
Vortex Cooler 04578009
Muffler for Cooler 04578010
Piston & Magnet Subassembly SD0452400
Replacement 1/2” Spherical Rod End 04570140
Guide Tube Support Bracket (See note 1) C0903400
Replacement (Male Connector) for Option “C2” Connector 04521407
Female Mating Connector for Option “C2” Connector 04521372
Replacement (Male Connector) for Option “C3” Connector 04521568
950 LDT Cable Assemblies
Item Part Number
SD0436700L6
Cable Assembly with Mate for Option "C" Connector Style, 6
Feet, (For 950A/950TP)
SD0436000L6
951, 952 and 953 LDT Cable Assemblies
Item Part Number
Cable Assembly with Mate for Option “C2” Connector Style, 6
Feet
SD0439700L6
5 Pin, Straight, Stainless Steel Cable Assembly with Mate for
Option “C3” Connector Style, 6 Feet
949013L6
6 Pin, Straight, Stainless Steel Cable Assembly with Mate for
Option “C4” Connector Style, 6 Feet
949031L6
PART NUMBERING
950MD 12A 0B 0C X X
Active Stroke in
Inches
Determine the
“active” stroke to be
measured followed
by “A”
Fully Retracted
Over-Stroke in Inches
Insert length of retracted over-
stroke in inches followed by
“B”. If no retract over-stroke is
required,
simply insert “0B”
Fully Extended
Over-Stroke in Inches
Insert length of extended over-stroke
in inches followed by “C”. If no
extended over-stroke is required,
simply insert “0C”
Note 1:
Guide tube support brackets are supplied as standard for strokes of 72" or greater.
Note 2: Special high temperature, abrasion resistant and oil resistant cables are available.
Consult your Customer Service Representative.
950MD Compatibility Guide
940 Yes
950IS Consult Factory
951 Yes (Must be ordered w/2” Null Zone & 5” Dead Band)
952 Yes (Must be ordered w/2” Null Zone & 5” Dead Band)
953 Yes (Must be ordered w/2” Null Zone & 5” Dead Band)
955 See 956 Section
7330 Consult Factory
Cable Assembly with Mate for Option "C" Connector Style, 6
Feet, (For 950-CP)
