HARDWARE PACKAGE
KEY QTY. DESCRIPTION
A 6 Hex Bolt, 1/4-20 x 1-3/4" Long
B 2 Hex Bolt, 1/4-20 x 1-1/2" Long
C 8 Hex Bolt, 1/4-20 x 3/4" Long
D 3 Carriage Bolt, 1/4-20 x 3/4" Long
E 16 Hex Lock Nut, 1/4-20 Thd.
F 20 Flat Washer, 5/16" SAE
G 8 Nylon Washer
H 4 Flat Washer, 1-5/8" x 25/32"
I 1 Cotter Pin, 1/8" x 1-1/2"
J 1 Cotter Pin, 3/32" x 3/4" Long
KEY QTY. DESCRIPTION
K 1 Flow Control Link
L 1 Spacer Tube, Short
M1 Spacer Tube, Long
N 1 Grip
O 1 Vinyl Cap
P 1 Nut, Plastic Wing 1/4"
Q 2 Handle Grip
R 1 Adjustable Stop
S 4 Swivel Bracket
T 2 Angle Stop Bracket
U 2 Plastic Knob
NOT FULL SIZE
FULL SIZE
G
H
I
A B
C
J
D E
F
K
L
M
N O
R
Q
P
S T
U
