REPAIR PARTS FOR MODEL 45-0315
REF.
NO.
PART
NO.
QTY.
DESCRIPTION
REF.
NO.
PART
NO.
QTY.
DESCRIPTION
1
47994BLK
1
Hopper
15
44663
2
Hub Cap (Push Nut)
2
48240
1
Frame Tube
16
46557
2
Push Nut, 1/2”
3
48241
1
Hitch Tube (LH)
17
24116
1
Drive Wheel Plate
4
48242
1
Hitch Tube (RH)
18
47851
2
Spacer
5
48243
1
Hitch Control Tube
19
64390
1
Impeller/Axle Assembly
6
43343
2
Hair Cotter Pin
20
47124
1
Impeller
7
1509-69
6
Hex Bolt, 1/4-20 x 1-3/4
21
47963
2
Hex Flange Bearing
8
43013
2
Hex Lock Nut, 1/4-20
22
24446
2
Hitch Bracket
9
43088
2
Washer, 1/4 Std
23
46978
8
Hex Nut, 1/4-20 (SEMS)
10
47316
1
Carriage Bolt 1/4-20 x 2-1/4
24
45164
4
Hex Bolt, 1/4-20 x 2-1/4
11
47141
1
Nylon Wing Nut 1/4-20
25
48545
3
Vinyl Cap
12
47983
1
Flow Slide
26
47623
1
Hitch Pin
13
47999
1
Control Cable
48257
1
Owners Manual
14
46503
2
Wheel & Tire
