SPECIFICATIONS NITESTAR NS-50/60
POWER: 9 to 16 VDC, negative ground.
OPERATING TEMPERATURE: 0 degrees C to +70 degrees C.
DISPLAY: 1.0 ft. to 999,999 ft. Liquid Crystal W/ Backlight
DISTANCE RESOLUTION: + 1.0 ft.
ACCURACY: up to +/- 1 ft./MI
AUTOMATIC ERROR CORRECTION: (AEC)
KEYBOARD: Touch-Tell Silicon Rubber Keyboard,
Tone Verification w/Backlight
KEY FUNCTION: On/Off, Run/Hold, Display/Hold, Clear/Reset,
Mark/Enter, Calibrate, Unit, Pre-Distance, Up/Down,
Brightness, Print, Speed, Periodic Distance Interval, Program,
View, Numeric 0-9
PRE-DISTANCE: 0-999.999 in unit of measurement
SENSOR: Solid State Proximity, Transmission or Electronic Interface
BI-DIRECTIONAL: Compute distance count up or down.
PDI: Count Display, TTL Output, (12 VDC 1 Amp with P/N 1050)
DIMENSIONS: 7.5" (190.5mm) x 2.25" (57.15mm) x .88" (22.5mm)
CALIBRATION: Auto Calibration Entry / Manual
WEIGHT: 7.0 oz. • UNIT: Auto conversion Ft, Miles, Km
SPEED: 0-199 mph, Kph, fps
MEMORY: Two digit code (0-99),
Unlimited memory locations, Non-Volatile Type
MATERIAL CALCULATION: Area, Volume, Tonnage, Cost
SPECIFICATIONS NITESTAR (NS-60 ONLY)
COMMUNICATION: RS-232 In /Out
PRINTER: Serial Type
SELECTABLE BAUD RATE: (300-600-1,200-2,400-4,800-9,600)
INPUT: (1) 8 Bit 0-5 VDC Analog (1) Digital
OUTPUT: (1) Digital TTL Level
45
USING HYPERTERMINAL
Start Hyperterminal by launching your new Nitestar icon.
You can now issue the CAPTURE TEXT command to your NS-60.
To save all the NS-60 data to a file, select CAPTURE TEXT:
and then:
Pick the file name you want to save the text as.
This file will contain all your NS-60 data.
