900-0137-01-00 Rev A 5
FX-Class Inverter Data Stream
This is the data stream generated for each FX-class inverter connected to the system. This includes all variants
on the FX such as VFX, GTFX, GVFX, and so on.
 The data stream for each inverter is 52 characters long.
 An example is 00,2,00,00,00,119,000,00,00,000,01,254,008,000,033.
 The items shown in Table 1 define the data stream by character. Specific descriptions for each category
begin on page 6.
Table 1 Data Stream Matrix for FX-Class Inverters
Character Definition Character Definition
1 New Line character, ASCII (10).
Denotes the start of the status page. 27 Tens digit of inverter operating mode.
2 Tens digit of Port number. 28 Units digit of inverter operating mode.
3 Units digit of Port number. 29 Comma, ASCII (44). Used as a data separator.
4 Comma, ASCII (44). Used as a data separator. 30 High digit of inverter Error status code.
5 Device type 2, ASCII (50). Indicates FX-class. 31 Middle digit of inverter Error status code.
6 Comma, ASCII (44). Used as a data separator. 32 Low digit of inverter Error status code.
7 Tens digit of Inverter current. 33 Comma, ASCII (44). Used as a data separator.
8 Units digit of Inverter current. 34 High digit of inverter AC mode.
9 Comma, ASCII (44). Used as a data separator. 35 Low digit of inverter AC mode.
10 Tens digit of Charger current. 36 Comma, ASCII (44). Used as a data separator.
11 Units digit of Charger current. 37 Tens digit of battery voltage.
12 Comma, ASCII (44). Used as a data separator. 38 Units digit of battery voltage.
13 Tens digit of Buy current. 39 Tenths digit of battery voltage.
14 Units digit of Buy current. 40 Comma, ASCII (44). Used as a data separator.
15 Comma, ASCII (44). Used as a data separator. 41 High byte of inverter Misc.
16 Hundreds digit of AC input voltage. 42 Middle byte of inverter Misc.
17 Tens digit of AC input voltage. 43 Low byte of inverter Misc.
18 Units digit of AC input voltage. 44 Comma, ASCII (44). Used as a data separator.
19 Comma, ASCII (44). Used as a data separator. 45 High digit of inverter Warning status code.
20 Hundreds digit of AC output voltage. 46 Middle digit of inverter Warning status code.
21 Tens digit of AC output voltage. 47 Low digit of inverter Warning status code.
22 Units digit of AC output voltage. 48 Comma, ASCII (44). Used as a data separator.
23 Comma, ASCII (44). Used as a data separator. 49 Hundreds digit of Checksum.
24 Tens digit of Sell current. 50 Tens digit of Checksum.
25 Units digit of Sell current. 51 Units digit of Checksum.
26 Comma, ASCII (44). Used as a data separator. 52 Carriage return, ASCII (13). Denotes the end of the
status page.
Star
t o
f St
atus
Pa
ge
Por
t A
ddr
ess
se
p
a
ra
to
r
Device Type
2
se
p
a
ra
to
r
Inver
ter
c
u
rr
ent
se
p
a
ra
to
r
C
har
ger
cur
re
nt
se
p
a
ra
to
r
Buy curren
t
se
p
a
ra
to
r
AC
i
nput
vol
ta
ge
se
p
a
ra
to
r
AC
out
p
ut
vol
ta
ge
se
p
a
ra
to
r
S
e
ll cu
rre
n
t
se
p
a
ra
to
r
Inver
ter
oper
a
ti
in
g
m
ode
se
p
a
ra
to
r
E
rro
r co
d
e
s
se
p
a
ra
to
r
AC
m
o
de
se
p
a
ra
to
r
Batt
ery volta
g
e
se
p
a
ra
to
r
Misc
se
p
a
ra
to
r
Warning co
des
se
p
a
ra
to
r
Checksum
End
of st
atus
pa
ge
ASCII
code
10 X X 44 50 44 X X 44 X X 44 X X 44 X X X 44 X X X 44 X X 44 X X 44 X X X 44 X X 44 X X X 44 X X X 44 X X X 44 X X X 13
Character 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52
