900-0137-01-00 Rev A 17
Commands
The MATE3 serial commands are text based, using a command and response method. For each command, there
is a corresponding response.
 Commands start with a “<” and end with a “>”.
 Responses start with a “ [ “ and end with a “ ] ”.
Example:
 PC sends the command (enable search mode).
 The MATE3 responds with [INV:1].
If the serial data stream is enabled, the response will be inserted between output lines of device status data. The
PC commands will operate if the serial data stream is disabled.
NOTE: Bulk, Absorption, and Float commands are universal commands sent to all ports. They cannot be sent to
individual devices. If a more extensive or flexible command set is needed, the OutBack AXS Port Modbus
Interface is recommended. (The AXS Port, however, can only send individual commands and not universal ones.)
Table 21 Command/Response Definitions
Command Response
Inverter Off
Search enabled
Inverter On
Returns current INV mode [INV:n]
n = 0-2
AC Drop
AC Use
Returns current AC input mode [AC:n]
n = 0,1
AUX On p = port 0-10
AUX Off p = port 0-10
Returns AUX state for port [AUX:p,s]
p = port 0-10,
s = state
0=Off,
1=On
Manual OFF Generator, if AGS is enabled
Manual ON Generator, if AGS is enabled
Auto Generator, if AGS is enabled
Returns current state of generator [GEN:s]
s = state,
0=Off,
1=On,
2= Auto
Set HBX disabled
Set HBX mode to voltage
Set HBX mode to SOC
Set HBX mode voltage and SOC
Returns current HBX mode [HBX:s]
s = state,
0=disabled,
1=HBX mode voltage,
2=HBX mode SOC,
3 = HBX mode voltage and SOC
