T M

HUB

Figure 1: Complete FLEXware 500 System installed (vertical installation is acceptable when
mounting space is limited)

Note: Although FLEXware 500 supports two MX Charge Controllers, both locations—top and
side—are shown in Figure 1.

Getting to Know FLEXware 500

IOB Kit

FW500-AC

FW Mounting Plate

DC Breakers

MX60 DC

FW500-DC

Disconnect

Breaker

AC Breakers

ACA

FX (with DCC)

DCA

2

MX60s
