5
Planning
Applications
The Radian Series Inverter/Charger is intended for both off-grid and grid-interactive (Grid/Hybrid)
applications. It is designed to use a battery bank to store energy. It can work in conjunction with
photovoltaic (PV) panels to harvest solar energy, as well as wind turbines and other renewable
sources. These sources charge the battery, which in turn is used by the inverter.
The Radian inverter has two sets of AC input terminals. Two AC sources, such as a gas or diesel
generator and the utility grid, can be connected to the inverter. Other combinations of AC sources
are possible.
NOTE: The inverter can only accept one source at a time. The input marked Grid has priority,
although this can be changed.
The Radian inverter’s settings can be changed to accommodate many applications.
Figure 3 Applications (Example)
