4 Cameras & 4 Channel DVR Video Security System Bundle
2
1.4 Technical Parameters
Features Description
Operating system Embedded LINUX OS
Video compression H.264
Video/Audio input 4/8 CH BNC
Video/ Audio output 1 CH BNC
Alarm intput/output 4/8 CH input 1 CH output
Display spilt 1/4/8-channel
VGA output Supports 800*600 1024*768 1280*1024@60Hz
Multiplex operation Live, recording, network, mobile phone
surveillance simultaneously
Recording mode Timer/manual/motion detection/alarm
Recording frame rate PAL：25fps NTSC：30fps adjustable
Recording quality High, normal ,low
Recording resolution CIF/Half-D1/D1
Recording playback 4/8 channel playback simultaneously
Recording backup Supports USB flash disk, mobile hard disk,
network backup, etc.
HDD Support 1 SATA HDD capacity to 2TB
Network transmission 4/8 channels real-time network transmission
with CIF resolution
Capture function Supported
Email alarm Send pictures to the designated Email box
PTZ control Supported
PTZ protocol PELCO-D,PELCO-P
PIP Supported
Zoom Supported
Network and protocol 1 RJ-45 10/100M via Ethernet, supports TCP/IP,
SMTP, DHCP, DNS, DDNS, NTP, etc.
IE browser Supported, max five users online
Client software Supported, max five users online
CMS Supported
Dual stream Supported（main and secondary interchange）
Multi-language Supported
Mobile phone surveillance Supported
Windows,Symbian,IPhone,Blackberry,Android
Mouse interface USB 1.1
Backup interface USB 2.0
Remote controller Supported
User authority Supports multi-level user authority distribution
Power DC12V/3A
Working temperature +14 ~ +122
°F (-10 ~ +50°C)
Working humidity 10%－90%
Dimensions (WxDxH) 10.8" x 8.4" x 1.8" (274 x 214 x 45 mm)
