4 Cameras & 4 Channel DVR Video Security System Bundle
29
Chapter 4 DVR Network
4.1 Functional Characteristics
The DVR supports LAN and WAN access, as well as IP and domain name access.
4.2 Installation and Download of Controls
Automatic installation of plug-ins unit:
First add the IP address of the DVR as a reliable site for your system. For example, if
the IP address of the DVR is 192.168.1.100, first open IE Attributes→Internet Options
→Security Options for an ordinary XP system, as shown below. This can be set in 9
steps.
After setup, enter the IP address in the IE address bar, and complete the automatic
installation of the plug-in unit as prompted.
4.3 IE Login
Log into the system after the plug-in unit has been installed. For example, if the domain
②click
⑤ click •
click
④cancel the optional ⑥
ƒ
Input IP
⑦ click
⑨
⑧ All selected "Enable"
Note: Enter the IP or Domain Name in the
third step without a port number
.
