4 Cameras & 4 Channel DVR Video Security System Bundle
11
3.3 Video Search
Enter the Video Search screen from Main Menu
→Video Search, as shown below. This
unit supports 3 video search modes:
A. Timing playback
Time input: First select the corresponding channel and then adjust the date and time
to be searched. Left-click or press "Enter" and the direction keys or enter digits
directly for year, month, date, hour, and minute adjustment, and then click "Playback"
to play back the record of this period of time. For 4-channel DVRs, the 4 channels
can be played back simultaneously.
B. Playback based on record state
Enter the year, month and date to be searched in the "Time Input" box and click
"Search" to view the record state of this date, as shown below:
Month: displays the recording information of every day in the current month. A
green block indicates normal recording, a red block indicates alarm recording, and
the background color indicates no recording. Click a date on this bar to search the
record information of every hour of that day. The search results will be visualized in
the "Day" bar below.
Date: displays the recording hours of the current day. Each lattice represents 1hr
and one recording segment is 0.5hr. The presentation of the record state is the
same as above. Click a 0.5hr segment of a day directly to enter the record
playback of this segment.
C. Playback based on file list
Enter the year, month and date to be searched in the "Time Input" box and click
"Search" to view the record state of this date. Click a certain day on the "Month" bar
then "FILE LIST", and the "FILE LIST" screen will pop up, as shown below:
Channel selection: There are 5 options: 1, 2, 3, 4 and all (9 options for 8-channel
DVR). After selection and confirmation the channel file to be displayed can be
selected in the following list.
Record type: There are 3 options: All, Normal, and Alarm. After selection and
confirmation, the searched message will be displayed automatically as a list, as
shown below:
