ZOOM/FOCUS LEVER DETAIL VIEW
f=2.8~10.5mm
f=2.8~11mm, 3.8~9.5mm
UNLOCK
UNLOCK
Rotation
T
Rotation
loosen the lever bolt and make necessary
adjustments.
Loosen Zoom& Focus lever bolt and
3. After adjustments, tighten the lever bolts to lock.
Focus
lever bolt
Zoom
lever bolt
T
