Monoprice 9744 Smooth Motion Wall Mount Bracket - Manual (Page 5)

8 7
Tighten all screws but do not over tighten.
Screw VESA plate onto the TV.
6. Hook the TV onto the Wall Mount
· Level the TV.
· Place the lower flat nut and tighten both nuts.
Loosen the upper nut spacing
4mm to VESA plate. Hook the TV onto the wall mount
4mm
or
TV
TV TV
TV
M-A/M-B
M-C/M-D
M-E
M-F
M-D
M-F
M-G
M-G
M-D
M-F
M-G
