Quick Mount LCD Monitor / TV Kit

Wall Plate

1

Use the2 / " wood screws,

4

mount the wall plate to wall stud

or use enclosed sheet rock mollies

1

Use the / " bolts, mount

2

the monitor plate to back of monitor,

(Note corners holes to accommodate

both 75mm or 100mm VESA systems)

1

Use the / " bolts to lock and secure

4

your monitor in place

Note: Bracket is intended

for use on LCD monitors up to 66lbs

VESA is a registered Trademark of the

Video Electronics Standards Association

R

LCD TV / Montior Plate

100mm

75mm

75mm

100mm

50mm

50mm

AS Easy as 1,2,3!

Step 1a

Step 1b

1

Using the2 / " wood screws and concrete

4

anchor mount the wall plate to wall

Pre-drill these mounting holes with a 8mm
masonry bit to an least 50mm in depth.

Step 2

Step 3

VESA is a registered Trademark of the
Video Electronics Standards Association

R

Simply silp your monitor onto your wall

1

mount, and secure with / " locking

4

bolts from below,

and you are finished! Enjoy!

1

Using the / " bolts,mount

2

the monitor plate to back monitor,

Depending on your monitor, Use the

75mm or 100mm pre-drilled holes

Instruction 1
2-sided page

Front

Back

1

Using the2 / " wood screws,

4

mount the wall plate to wall stud
