Note: Read entire instruction sheet before you start installation and assembly.
Table of Contents
Parts List .......................................................................................................................................................................... 3
Installation of Single Wood Stud Wall ................................................................................................................................... 4
Installation of Solid Concrete and Cinder Block .................................................................................................................... 5
Attaching mount to Screen with VESA ® Mounting Patterns .................................................................................. 6
Adjustment of Flat Panel Screen ............................................................................................................... .............................................. 7
Tools Needed for Assembly
‡ stud finder ("edge to edge" stud finder is recommended)
‡ phillips screwdriver
‡ pencil
‡ drill
‡ 1/8" drill bit for wood studs, 5/16" drill bit for concrete
‡ level
‡ tape measure
WARNING
‡ Be sure to read this entire manual thoroughly and you fully understand all the instructions and warning before
attempting to begin your installation.
‡ This product should only be installed by someone who has a basic knowledge of buiding construction,in stallations
and fully understands these instructions.
‡ Make sure that the supporting surface will safely support the combined load of the mount, the display and all
attached hardware and components.
‡ The maximum load capacity is 30 pounds.
‡ If mounting to a wall of wood stud construction, be sure that mounting bolts are anchored to the center of the
studs.
‡ Always have someone assist you to lift and position your equipment.
‡ Tighten screws and bolts firmly, but do not over tighten. Over tightening can damage the items and greatly reduce
their ability to hold. Please refer to suggested torque values where applicable in these instructions.
