2010-2013 Ford F-150 Raptor SVT 6.2L V8

Cold Air Induction Kit

Part # 1831


3

INS-184

STEP 7

STEP 9

Install the sponge trimming onto the BBK Cold
Air Intake shield and install the supplied plug
into the BBK Air Filter.

STEP 10

STEP 8

Remove the factory vent hose and replace it
with the supplied 3/8” hose. Connect the
supplied 3/8” hose to the plastic straight fitting
on the BBK Intake Tube. The Valve Cover vent
hose with the clip will be connected to the larger
welded tube coming off the BBK Intake Tube.
NOTE!!! Be sure that the clipped vent hose
is pushed onto the welded tube until it clicks
into place.

Place the cold air shield into the vehicle on the
bottom half of the factory air box and use the
three original clamps to secure the shield.

Install the blue BBK Coupler and BBK Intake
Tube to the throttle body.
