BBK Performance 18315 - Manual (Page 2)

2010-2013 Ford F-150 Raptor SVT 6.2L V8
Cold Air Induction Kit
Part # 1831
2
INS-184
STEP 4 STEP 5
STEP 6
•
Install the supplied rubber grommet and straight
fitting into the BBK Cold Air Tube.
•
Unclip the three clips at the air box and remove
the entire system out of the vehicle.
NOTE!!! The rubber coupler also needs to be
removed from the throttle body.
•
Remove the MAF Sensor from the stock intake
system using a T-20 Torx and install it into the
BBK Cold Air Tube using the supplied
hardware. NOTE!!! The Air Flow of the sensor
needs to be going towards the throttle body,
the sensor should only fit one way because
of the stagger in the hole pattern.
