American Standard 3698.016 - Manual (Page 2)

5
6
7
8
INSTALL TOILET ON FLANGE
a. Unplug wall waste opening and slide
toilet towards closet flange so bolts
project through mounting holes.
b. Loosely install retainer tapered washers
and nuts. Side of washers marked
"THIS SIDE UP" must face you!
INSTALL TOILET
a. Position toilet squarely to wall and, with a rocking
motion, push bowl against ring and flange.
Alternately tighten nuts until toilet is firmly anchored.
CAUTION: DO NOT OVERTIGHTEN NUTS
OR BASE MAY BE DAMAGED!
b. Insert the tapered washers (supplied in the kit)
into the lag bolts (not supplied). Insert bolts
through mounting holes and tighten into
pre-drilled floor openings.
c. Install the bolt caps on tapered washers. (If
necessary, cut wall bolt length to size before
installing caps.)
d. Smooth off the bead of sealant around base.
Remove excess sealant.
BOLT HEAD WASHER
BOLT
CAP
!
- 2 - 7 3 0 1 1 9 8 - 1 0 0
BOLT
CAP
NUT &
WASHER
When cleaning your toilet, wash it with mild, soapy water, rinse thoroughly with clear water and dry with a soft cloth. Avoid detergents,
disinfectants, or cleaning products in aerosol cans. NEVER use abrasive scouring powders or abrasive pads on your toilet seat.
Some bathroom chemicals and cosmetics may damage the seat's finish.
INSTALL TOILET SEAT Install toilet seat in accordance with manufacturer's directions.
In the United States:
American Standard Inc.
P.O. Box 6820
Piscataway, New Jersey 08855
Attention: Director of Consumer Affairs
For residents of the United States, warranty
information may also be obtained by calling
the following toll free number: (800) 442-1902
www.americanstandard-us.com
In Canada:
American Standard
2480 Stanfield Rd.
Mississauga, Ontario
Canada L4Y 1S2
Toll Free: (800) 387-0369
www.americanstandard.ca
In Mexico:
Customer Service Manager
Ideal Standard, S.A. de C.V.
Via Morelos #330
Col. Santa Clara
Ecatepec 55540 Edo. Mexico
www.americanstandard.com.mx
AS AMERICA, INC. ONE-YEAR LIMITED WARRANTY
If inspection of this AS America, Inc. (“American Standard”) plumbing product, within one year after its initial purchase, confirms that it is defective in materials
or workmanship, American Standard will repair or, at its option, exchange the product for a similar model.
This warranty does not apply to local building code compliance. Since local building codes vary considerably, the purchaser of this product should check with a
local building or plumbing contractor to insure local code compliance before installation.
This warranty shall be void if the product has been moved from its initial place of installation; if it has been subjected to faulty maintenance, abuse, misuse,
accident or other damage; if it was not installed in accordance with American Standard's instructions; or if it has been modified in a manner inconsistent with the
product as shipped by American Standard.
American Standard's option to repair or exchange the product under this warranty does not cover any labor or other costs of removal or installation, nor shall
American Standard be responsible for any other incidental or consequential damages attributable to a product defect or to the repair or exchange of
a defective product, all of which are expressly excluded from this warranty. (Some states or provinces do not allow the exclusion or limitation of implied
warranties, so this exclusion may not apply to you.)
This warranty gives you specific legal rights. You may have other statutory rights that vary from state to state or from province to province, in which case this
warranty does not affect such statutory rights.
For service under this warranty, it is suggested that a claim be made through the contractor or dealer from or through whom the product was purchased, or that
a service request (including a description of the product model and of the defect) be sent to the following address:
CARE AND CLEANING
LAG
BOLT
TAPERED
WASHERS
FLANGE
FLANGE
BOLTS
