Telenav for T-Mobile Supported Devices: v5.5 for T-Mobile Sidekick LX - Manual (Page 28)

Traffic Summary
Displays overall delay from traffic, a summary of incidents on the
route, and the average speed for each segment where available.
You can click on any line to view more details.
Below is an explanation of what you will see on the Traffic Alert
screen:
• Incidents (triangle icons) – Total number of remaining
incidents directly along the route. The color of the
triangle indicates incident severity:
Color Severity
Yellow Only Minor incidents
Orange At least one Major incident,
no severe incidents
Red At least one Severe incident
• Delay – Total time delay caused by traffic conditions, or the sum of delays on each segment.
NOTE: Delay refers only to the route currently shown.
• Go – Distance until next turn.
NOTE: This is not the distance from the origin but the length of each road segment.
• Street – The street or highway name of the road segment.
• Mph/Kph – Average speed on that road segment.
NOTE: “N/A” is displayed for segments without traffic flow information (usually local streets) or segments
farther than 200 miles away.
If you click on an incident line, you can view the details. Below is an
explanation of what you will see on the Traffic Detail screen:
• Delay – The additional time it will take to travel the
segment as compared with the time it would take if
traveling at the posted speed.
• Travel Time – Estimated time it will take to travel the
segment.
• Slowest Speed – Slowest speed observed on the
segment.
• Average Speed Bar – Average speed of a segment on
a scale of 0 to the maximum-posted speed for that
segment.
© TELENAV, INC. 2003-2009 PAGE 28 OF 57
