Sper Scientific 850039 Conductivity TDS Meter - Datalogging - Manual (Page 8)

- 8 -
4-F. Temperature Unit Default Setting
 Press the SET (8) button as needed to reach the "temp. unit"
screen.
 Use the ▲ (5) and ▼ (6) buttons to switch between °F and °C.
Press the ENTER (4) button.
 Press the SET (8) button to advance to the next option, or press the ESC
(3) button to exit.
4-G. Temperature Compensation Factor (ATC) Default Setting
The ATC Factor is adjustable between 0 to 5.0% per °C.
 Press the SET (8) button as needed to reach the
"Temp. Comp." screen.
 Use the ▲ (5), ▼ (6), and SEND (7) buttons to set the
ATC Factor.
 Press the ENTER (4) button to save the settings.
 Press the SET (8) button to advance to the next option, or press the ESC
(3) button to exit.
4-H. Conductivity (uS, mS), TDS (PPM) Default Setting
 Press the SET (8) button as needed to reach the "CD/TDS"
screen.
 Use the ▲ (5) and ▼ (6) buttons to switch between uS, mS and PPM.
 Press the ENTER (4) button.
 Press the SET (8) button to advance to the next option, or press the ESC
(3) button to exit.
4-I. Escape from Advanced Adjustments
For the above procedures, press the ESC (3) button before pressing the EN-
TER
(4) button to exit advanced adjustments without saving the changes.
5. UPLOADING DATA FROM THE METER
(Auto data logging readings only—manual readings cannot be upload-
ed)
To upload the data to a computer, connect the RS232 cable and run the soft-
ware (see page 11). You can only send one memory block at a time.
 First, cancel the hold and record functions if they are activated.
 Press the SEND (7) button for at least 2 seconds until the bottom right dis-
play shows "Transmit Mode."
 Release the button.
 The following screens flash alternately:
1=PPM
0=uS, mS
Temp. Comp.
^, v SEND(→)
1=°F
0=°C
