Getting Started
2-6
AT85DVK-07 Demonstration Firmware User’s Manual
7687C–MP3–09/07
2.3
Power-Up
There are two ways to power-up the system:
•
USB powered: the USB cable is connected to the board and to a PC
•
Battery Powered: a battery is inserted in its socket, the Power On key is pressed.
Note that the battery can be replaced by an external power-supply connected to J20
(see the AT85DVK-07 Hardware User’s Guide for further information).
A short animation followed by the Atmel logo will be displayed during few seconds, giv-
ing the version of the firmware and NandFlash manufacturer IDs:
Note:
To skip the display, press a key.
If the board is powered using the battery, the Main Menu application is launched:
If the board is powered by the USB cable (device mode), the Mass-Storage application
is automatically launched:
NandFlash Manufacturer ID
NandFlash Device ID
