Operating Modes
AT85DVK-07 Demonstration Firmware User’s Manual 3-17
7687C–MP3–09/07
3.10 Settings The Settings application allows the end-user to configure the player, to get some status
of the system and to execute specific functions.
The topics of the Setting application are detailed in the following sections:
• Language
• Power
• Format
• Version
• Update System
• Update Settings
• Exit
3.10.1 Language This topic allows to choose the player language.
3.10.2 Power This topic allows to configure some timing in order to optimize the power consumption:
• Power Off
• Backlight
• Backlight time-out
3.10.3 Format This topic allows to format the on-board Nand Flash. The format feature is also accessi-
ble in the Explorer application as described in Section 3.4.2.8.
3.10.4 Version This topic allows to display all codec + firmware versions.
3.10.5 Update System This topic allows to launch the Explorer application in order to select an update file as
described in Section 3.11.2.
3.10.6 Update Settings This topic allows to update the user’s settings with the file: “settings.dat” stored in the
“C:\Update” directory.
Notes: 1. The update directory location (directory or disk) as well as update file name can be
easily modified at compile time by configuring the conf_explorer.h file.
2. The structure of the file must comply to the structure “struct_setting” defined in the
com_var.h file
3.10.7 Exit This topic allows to exit the Settings application. The Settings application can also be
exit at any time by pressing the Left key
