Operating Modes
3-12 AT85DVK-07 Demonstration Firmware User’s Manual
7687C–MP3–09/07
3.4 Explorer To enter the Explorer application (disk selection screen), select the Explorer icon from
the main menu:.
Disk A: stands for the Nand Flash memory; while disk B: stands for the MMC/SD card.
Navigation is intuitive: press the Right key to enter into a disk or a directory, the Left key
to go back to the upper folder. Press the Up and Down keys to navigate into the files.
To play a disk, a folder or a file, put the cursor on the corresponding location with the
joystick, then press the Select key. The explorer will automatically launch the player
module on the selected disk/folder/file.
Note: The playback will only be made inside the selection. At its end, the player will restart on
the first file of the selection.
3.4.1 USB Host In case a USB mass-storage device is connected to the board (refer to the procedure
described in the AT85DVK-07 Hardware User’s Guide), a new disk is mounted in the
explorer:
Disk C to Z: stands for the USB devices, Host status is displayed on the bottom of the
screen according to Section 3.1.3.
3.4.2 Contextual Menu To enter the contextual menu, follow the sequence described in Section 3.2.2.
Once the menu is displayed, press the Up or Down keys to select one of the following
functions:
Confirm your choice by pressing the Select key.
Main Menu
Copy
Add to Playlist
Properties
Disk Selection
Paste
Delete
Format
Select Playlist
