Mc Leod 4400 Series Truck Pull User Manual
Page 5
6) Closely inspect pilot bearing or bushing for excessive wear to avoid transmission shaft
misalignment. Replace it if any doubts.
7) Use clutch alignment tool to insure disc and cover are properly aligned with pilot bearing.
8) If using an aftermarket scatter shield/bell housing, checking center hole run-out is highly
recommended.
9) Be sure all special type bolts, if any, are replaced in their proper locations.
10) Torque all clutch cover bolts evenly, to factory recommended spec, using a progressive “criss-
cross” tightening pattern.
11) Before completing installation, inspect all clutch linkage parts (fork, clevis, pins, etc.) for signs of
wear and replace ALL worn pieces. Grease all pivot points in linkage system.
12) Adjust clutch pedal “free play” to correct specifications. Throw-out bearing should not be tight
against clutch fingers. 1/8” – ¼” is recommended, except cable linkage.
Installation / Don’ts
Torque Specs
1) Don’t let any grease or oil contact ANY friction Surface.
5/16-18 Grade 8 25 Ft/Lbs
2) Don’t use an impact (air gun) to tighten cover bolts. 3/8-16 Grade 8 35 Ft/Lbs
Don’t let transmission weight rest on input shaft during 7/16-20 Grade 8 65 Ft/Lbs
installation.
½-20 Grade 8 75 Ft/Lbs
Limited Warranty
McLeod Racing LLC, Products are warranted to be free from defects in material and workmanship for the
period of ninety (90) days, from the date of purchase. McLeod does not warrant or make any
representations concerning its products when not installed and used strictly in accordance with the
manufacturer’s instructions for such; installation and operation, and in accordance with good installation
and maintenance practices of the automotive industry. McLeod will not be held liable for the labor
charges and other intangible or consequent losses that might be claimed as a result of the failure of any
part, nor shall it be liable for damages or injury to persons or property resulting from the misuse or
improper installation of any part subject to this warranty.
No merchandise may be returned for any reason unless prior return merchandise authorization number
(RMA) has been obtained from McLeod.
McLeod reserves the right to examine all parts returned for warranty claim to determine whether or not
any such part has failed because of a defect in material or workmanship. McLeod obligation under this
warranty shall be limited to repairing, replacing or crediting, at its option, any part found to be defective.
All products returned to McLeod for warranty inspection must be prepaid by the customer under this
warranty. There are no other warranties, either expressed or implied, which extend beyond those set
forth in the preceding paragraphs.
McLeod Racing, LLC 1600 Sierra Madre Circle Placentia, CA 92870
714.630.2764
I0022
