Equus 3340 - Automotive DMM (10 MegOhm / UL) - Manual (Page 7)

AC CURRENT (AMPS)
BATTERY TEST
DIODE/CONTINUITY TESTS
TEMPERATURE
6
E
Function Range Resolution Description Note
Diode Test 2V 1mV Test Current:
1±0.6mA
Test Voltage:
Overload
Approx. 2.8V Protection:
Continuity 400
Ω
0.1
Ω
Approx. 120
Ω
or 250V DC or
Test less, buzzer AC RMS
(beeper) will
sound
Range Resolution Accuracy Overload Protection
40mA 10
µ
A ± (2.0% of
0.5A/250V fast fuse
400mA 100
µ
A reading
+ 5 digits)
Input Voltage Drop: <0.2V.
Frequency response: 50 - 400Hz
Range Resolution DC Current Load
1.5V
9V 10mV 10mA
Range Accuracy Overload Protection
32°F to 104°F ±5°F/±3°C
(0°C to 40°C)
-58°F to 392°F ±1.5%/±5°F
(-50°C to 200°C) (±1.5%/±3°C) 0.5A/250V fast fuse
392°F to 752°F ±2%/±5°F
(200°C to 400°C) (±2%/±3°C)
WARNING
To avoid fire and/or electrical shock hazards, DO NOT con-
nect the thermocouples to circuits greater than 30 Vrms, 42.4
Vpk or 60 Vdc.
