AC VOLTS
RESISTANCE (OHMS)
DC CURRENT (AMPS)
5
E
Range Resolution Accuracy Overload Protection
40mA 10
µ
A
± (1.5% of 0.5A/250V fast fuse
reading (Input Voltage
400mA 100 µ A + 5 digits) Drop: <0.2V.
± (2.5% of
Unfused; 15sec maximum
*15A 10mA reading
Input Voltage Drop: <0.2V.
+ 5 digits)
*A waiting period of at least 15 minutes is necessary between
every 15 second testing period.
Range Resolution Accuracy Overload Protection
400
Ω
0.1
Ω
4k
Ω
1
Ω ± (1.0% of
40k Ω 10 Ω reading
400k Ω 100 Ω
+ 5 digits)
250V DC/AC
4M Ω ± (2.0% of
40M Ω 10k
Ω
reading
+ 5 digits)
Range Resolution Accuracy Overload Protection
400mV 100
µ
V ± (1.2% of 250V DC RMS
reading
+8 digits)
4V 1mV ± (0.8% of
40V 10mV
reading
400V
+ 8 digits)
600V DC/AC RMS
600V
1V ± (1.2% of
reading
+ 8 digits)
Input impedance: 10M
Ω
for all ranges.
Frequency response: 50 - 400Hz
