Holographic Window - Contains the embedded holographic reticle pattern that forms a virtual
image of the reticle when illuminated by laser light.
Protective Hood - Preassembled, protective hood increases durability of sight housing and
protects the sight from impact damage.
Battery Cap- A threaded cap that secures and seals the battery compartment to prevent water,
dirt, or grime from entering the battery housing.
Universal Mount - Ambidextrous, quick release base mounts to either a 1” (25.4mm) Weaver or MIL-
STD-1913 rail. Adjustable lever accommodates all MIL-STD 1913 rail tolerances.
Windage Adjustment - Adjusts the point of impact
1
/
2
MOA per click in a leftward and rightward
direction.
Elevation Adjustment - Adjusts the point of impact
1
/
2
MOA per click in an upward and down-
ward direction.
On/Off, and Brightness Switches - Raised button control interface allows the operator to perform and
adjust user settings for appropriate and preferred conditions (see page 14).
8
