MOTOR AND ICE CONTAINER PARTS
8
For Model: ASD2522VRW00, ASD2522VRB00, ASD2522VRS00, ASD2522VRD00
(White) (Black) (Stainless) (Universal Silver)
W10182979
Illus. Part
No. No. DESCRIPTION
1 2254587 Bracket, Motor
2 2188385 Motor, Dispenser
3 2152713 Soleniod Assembly
4 2149100 Guide, Soleniod
6 1115374 Clip, Wiring
7 2206501 Wiring Assembly,
Ice Dispenser
8 489399 Screw
9 W10169511 Coupling, Motor
10 489478 Screw
11 2162085 Socket, Light
12 2196091 Ice Container
13 1119005 Spacer, Step (3)
14 1119007 Spacer, Flat (2)
15 2257022 Blade, Rotary
16 2257023 Blade, Rotary
17 2257024 Blade, Rotary
18 489235 Washer, Plain
19 1119009 Blade, Fixed (2)
20 2157405 Block, Blade
21 489229 Roll Pin
22 2196295 Auger
23 2305377 Drum
24 2171682 Floating Baffle
25 1119018 Nut, Bearing
26 2155231 Control Arm
27 1119020 Spring, Return
28 1119021 Retainer Clip, Rod
29 488886 Screw
30 2180348 Housing, Crusher
31 1119017 Deflector, Ice
32 489234 Washer, Plain
33 489236 Retainer Ring
34 2204321 Front Cover,
Ice Container
35 527949 Light Bulb
36 2171706 Light Lens,
Dispenser
100 2209780 Ice Container
Assembly
