6
FREEZER LINER PARTS
For Model: ASD2522VRW00, ASD2522VRB00, ASD2522VRS00, ASD2522VRD00
(White) (Black) (Stainless) (Universal Silver)
W10182979
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 2171713K Door, Ice
Compartment
3 842534 Clip, Air Duct (2)
4 2196206 Support, Stud (4)
5 3400893 Screw
6 2176134 Grommet
7 2182971 Freezer Bin
8 Slide, Basket
2261449 Right Side
2261448 Left Side
9 W10004810 Screw
10 1115373 Switch, Rocker Arm
11 8281158 Screw
12 2196483 Stud Assembly
13 3400893 Screw
14 2171714K Shelf, Top
Compartment
15 2171705 Lens, Light
16 527949 Light Bulb
17 2162085 Light Socket
18 2196207 Stud, Rear
19 Slide, Container
1119237 Left Side
1119293 Right Side
20 489100 Screw
21 2174268K Shelf (2)
2174267K Shelf (1)
