UNIT PARTS
16
For Model: ASD2522VRW00, ASD2522VRB00, ASD2522VRS00, ASD2522VRD00
(White) (Black) (Stainless) (Universal Silver)
W10182979
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1
2169104 Insulation, Sound
2
2225834 Fan, Blade
3 W10121487 Condenser
Assembly
(Also Order #7)
4
489464 Screw
5
2208280 Clip, Wire
6
8533993 Screw
7 W10132427 Bushing,
Compressor
8
2161302 Sleeve
9
2255130 Capacitor
10
2216914 Clip, Condenser
11
2212996 Strap, Bale
12
2313162 Start−Device,
Combination
(Start Relay and
Overload)
13
2313230 Tube Suction
14
489478 Screw
15
2188823 Evaporator
16
2161324 Clamp
17 W10130108 Fan, Motor
18
1105523 Tray, Evaporator
19
2217194 Heat Shield
(Includes #26)
20
Drier
2319825 Production
W10143759 Service
21 W10140971 Compressor
(Includes Items
9, 12, 20 & 28)
(Also Order
876765 Tube Kit)
22
2304904 Unit Mounting
Frame
23
4389205 Unit, Harness
24
2181929 Fan, Motor Bracket
25
2323198 Heater, Defrost
26
2304287 Clip
27
489373 Screw (4)
28
4388295 Grommet (4)
29
489340 Screw
30
2196202 Air Baffle
31
2155547 Clip, Heat Shield
32
2304899 Unit Cover, Bottom
33
489396 Clip
34
2305374 Unit Mounting
Rail
35
8281232 Screw
36
2260517 Guard, Fan
37
489427 Screw
38
488649 Screw
39
2320322 Connector, Water
Tube
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.0 oz.
(R−134A)
