Introduction
Thank you for purchasing the CE-PTZ-WP24. This manual will provide basic information about this product, and important notices which should
be read before starting the installation. Please note that improper installation or use other than described in this manual may cause damage to the
device, and void the warranty.
CE-PTZ-WP24 Specifications
Outdoor Box
Power Requirement: AC24V
Temperature: -4ºF to 140ºF
Contains connector board without power transformer.
AC24VIN
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
H&F
AC24V
AUX1 AUX2
COM ALM1 ALM2 ALM3 ALM4 ALM5 ALM6 ALM7 485A + 485B - 485A + 485B -
AC24V
AC220V
AC220V
COM
JP2
JP2_2
AC24V FUSE
J1
FUSE 5X20
Alarm Inputs 485 Inputs
Ground
24V Input Auxilary Inputs
Common Common
220V Aux. Input
Alarm/Aux/Com
Output 1 to Camera
AC24V Output
to Camera
AC24V Aux. Input
5 x 20mm fuse
3A 250V
RS485 Communication
Output to Camera
Heater &
Fan Output
JP9
NOT USED WITH STANDARD SETUP
220V Aux. Input
Alarm/Aux/Com
Output 2 to Camera
IN
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
H&F AC24V
AUX1 AUX2
CO
M
ALM1 ALM2 ALM3 ALM4 ALM5 ALM6 ALM7 485A 485B 485A 485B AC24V
AC220V
AC220V
CO
M
JP2 JP2_2
AC24V FUSE
J1
FUSE 5X20
Outdoor Box
Model CE-PTZ-WP24
0204201792
2.12 in (54mm)
9.41 in (239mm)
.39 in (9.9mm)
7.94 in (202mm)
4.48 in (114mm)
6.10 in (155mm)
8.46 in (215mm)
6.69 in (170mm)
JP9
5.55 in (141mm)
Included Accessories:
