CLINTON Electronics
6701 Clinton Road
Loves Park, IL 61111
1.800.447.3306 Sales
1.800.549.6393 Support
1.800.633.8712 Fax
www.clintonelectronics.com
Outdoor Cable Distribution Box
CE-PTZ-WP24
User Manual
AC24VIN
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
H&F
AC24V
AUX1
AUX2
COM ALM1 ALM2 ALM3 ALM4 ALM5 ALM6 ALM7 485A + 485B - 485A + 485B -
AC24V
AC220V
AC220V
COM
JP2
JP2_2
AC24V FUSE
J1
FUSE 5X20
Alarm Inputs 485 Inputs
Ground
24V Input Auxilary Inputs
Common Common
220V Aux. Input
Alarm/Aux/Com
Output 1 to Camera
AC24V Output
to Camera
AC24V Aux. Input
5 x 20mm fuse
3A 250V
RS485 Communication
Output to Camera
Heater &
Fan Output
JP9
NOT USED WITH STANDARD SETUP
220V Aux. Input
Alarm/Aux/Com
Output 2 to Camera
IN
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
H&F AC24V
AUX1 AUX2
CO
M
ALM1 ALM2 ALM3 ALM4 ALM5 ALM6 ALM7 485A 485B 485A 485B
AC24V
AC220V
AC220V
CO
M
JP2 JP2_2
AC24V FUSE
J1
FUSE 5X20
Outdoor Box
Model CE-PTZ-WP24
0204201792
2.12 in (54mm)
9.41 in (239mm)
.39 in (9.9mm)
7.94 in (202mm)
4.48 in (114mm)
6.10 in (155mm)
8.46 in (215mm)
6.69 in (170mm)
JP9
5.55 in (141mm)
