14
1. When the SETUP menu screen is displayed, select ‘BACKLIGHT’ by using the Up and Down
buttons so that the arrow indicates ‘BACKLIGHT’.
2. Select a desired mode using the Left and Right buttons depending on the camera purpose.
 BLC: Enables a user to select a desired area on a picture and view that area more clearly.
HLC (High Light Compensation) : If the scene contains extremely bright light areas such as from
car headlight, the light can mask out much of the on-screen detail. Use HLC feature to remove
these exceptionally bright lit areas to allow detail such as car license plate number to become
visible.
– LEVEL: Adjust level of the HLC function.
– LIMIT: Enable to change the operating condition.
– MASK COLOR/TONE : Change the color / brightness of the masking area.
(Black, Red, Blue, Cyan, Magenta)
– TOP/BOTTOM/LEFT/RIGHT : Adjust the area to be enhanced.
OFF : Not being used.
BLC (Back Light Compensation)
BLC ON
BLC OFF

HLC ON HLC OFF
HLC MASKING AREA

