10
3. Select a menu item from the list available by using the UP and DOWN buttons.
• Functions are selected using up and down buttons.
• Place the cursor over a desired item, the selected position is displayed.
4. Set up a selected item by using the Left and Right buttons.
5. To finish the settings, select ‘EXIT’ and press the SET button.
Accessing the OSD Menu
Notes
• An item with the icon also has sub menus. To select a sub menu, select
an item with the icon and press the SET button.
• An item with the - - - icon has no sub-menus available for selection.
Select the function
using the UP or
DOWN button.
Change the status
using the LEFT or
RIGHT button.
When an arrow
is present, press
SETUP button to
enter sub-menu
LENS (Adjusting the brightness level)
Using this function, you can control the screen brightness.
1. When the SETUP menu screen is displayed, select ‘LENS’ by using the Up and Down buttons
so that the arrow indicates ‘LENS’.
2. Press SETUP to enter the sub menu and adjust the following.
– BRIGHTNESS : Adjusts the video brightness (selectable from 1 - 70).
Notes
• When using an auto iris lens, the setting of the auto iris lens selection switch
located on the back of the camera must be on DC or VIDEO depending on
the type of lens which is being used. (Refer to the picture on page 8)
• If color rolling occurs when using a DC lens, set Shutter to A.FLK.
• Some lenses may not work properly, depending on the setting of the
BRIGHTNESS LEVEL.
