22 | PIM 21 User’s Manual
Specifications
Specifications
Measurement type: Single port reflection PIM measurement.
Carrier Power
Cellular
+20 to +33 dBm, in 1dB steps
PCS +20 to +30 dBm, in 1dB steps
Power accuracy: ± 1 dB / carrier
Carrier frequencies*: Depending on type
Measurement frequency*: Depending on type
Measurement range: -80 dBc to -150 dBc, typically to -155 dBc
Measurement accuracy: ± 2 dB to -153 dBc
± 3 dB to -155 dBc
Frequency accuracy: ± 2 p.p.m., 0 to 50°C
Measurement displays 3 digit numeric backlit, 16 x 2, LCD display,
16 LED bar graph, (transition green to red at -140 dBc)
and variable tone audio
VSWR measurement: LCD and LED Alarm,
Trigger adjustable from -6 to -16 dB Return Loss.
VSWR measurement: < 12 dB Return Loss ± 3 dB
Accuracy > 12dB calculated indication only
External interface(s): ON/OFF contacts for PIM alarm (adjustable) and audio tone
output. 2.5 mm and 3.5 mm stereo phone sockets.
Measurement connector: 7/16 mm DIN Female
Power requirement: External DC input 10 to16 V @ 3.5 Amps max
Internal Battery: Sealed Lead Acid, 1 hour continuous operation
(with +30 dBm carriers)
Charging Time: 4 to 5 Hours. No damage for continuous charging.
Weight: < 8 kg (17.6 lbs) nominal.
Dimensions, L x W x D: 34.3 x 32.7 x 15.2 cm (13.5 x 12.9 x 6.0 inches)
Enclosure: Weather-proof Pelican TM 1400 case.
Operating Temp: 0 to 45°C / 10 ~ 85 % humidity, (non condensing)
Storage Temp: -10 to 60°C / 10 ~ 85 % humidity, (non condensing)
IP rating: IP55 Lid closed (storage) and
IP40 lid open (operational).
*Frequencies will be customized. For additional information see also table in the addendum.
