SWIVEL HITCH ASSEMBLY
I-130 TS2
A125223
KEY # PART NUMBER QUANTITY REQUIRED DESCRIPTION
A25223-0 Yoke: A-Frame
2 A25223-02 Swivel
3 A25223-03 Bracket: 0 Hole
4 A25223-04 Pin: Main Vertical
5 A25223-05 Spacer: 6”
6 A25223-06 Pin Horizontal
7 A25223-07 4 Bushing
8 A25223-08 2 Seal: O-ring
9 A25223-09 2 Seal: O-ring
0 AFH-00028 2 Grease Fitting: 90°
A25223- 2 Washer- -/2” For Horizontal Pin
2 A25223-2 Nut: Slotted -/2” NC
3 A25223-3 Spacer: 6”
4 A25223-4 2 Washer: 2 /2”
5 A25223-5 Nut: Slotted 2-/2” NC
6 A25223-6 Sleeve: 2” Rubber
7 A25223-7 Cap: For Vertical Pin
8 A25223-8 Pin: Cotter 3/8 x 5”
9 4505 4 Grease Fitting Straight
20 863 Cotter Pin: 5/6 x 2-/2”
2 A25056-24 2 Bushing
22 A25056-27 2 Bushing
