Ashland I-130TS2 User Manual
Page 15
5
KEY NO.
PART NO.
DESCRIPTION
.
A2576-0
Barrel Weldment ()
2.
A2576-20
Shaft ()
3.
A2576-32
Spacer ()
4.
A2576-30
Piston ()
5.
A2576-3
Head ()
6.
A2575-33
/4” Nylock Nut ()
8.
A2576-40
Seal Kit ()
9.
A2575-35
Bearing
0.
A2575-36
Snap Ring
.
A2575-37
Grease Zerk ()
I-30 Push Gate Cylinder Assembly
Part Number A2576
4 /2” BORE X 54” STROKE
