Ashland I-110TS - Manual (Page 9)

KEY NO. PART NO. DESCRIPTION
1 A123302 Bowl and Frame I-110TS
2 AFB-00094 Flange Bolt, 3/8” NC x 1”
3 A10157 Left hand cylinder guard
4 A10158 Right hand cylinder guard
7 A123332L Left cutting edge, 8”
8 A123331 Center cutting edge, 12” x 54”
9 A123332R Right cutting edge, 8”
10 PB9P-NC-088-0275 Plow bolt, 7/8” NC x 2-3/4” (12 req’d.)
AFN-00019 Nut: 7/8” NC (12 req’d./ center blade)
11 A123338L (Optional) Left Bank Shaver Side Blade
12 A123338R (Optional) Right Bank Shaver Side Blade
13 PB9P-NC-088-0275 Plow bolt, 7/8” NC x 2-3/4” (6 req’d./ corner blade)
AFN-00019 Nut: 7/8” NC (6 req’d./ corner blade)
14 PB9P-NC-088-0275 Plow bolt, 7/8” NC x 2-3/4” (4 req’d./ shaver blade)
AFN-00019 Nut: 7/8” NC (4 req’d./ shaver blade)
PB9P-NC-088-0225 Plow bolt, 7/8” NC x 2-1/4” (3 req’d./ shaver blade)
AFN-00026 Nut: 7/8” NC Jam (3 req’d./ shaver blade)
